Product Details

  • This range has been carefully crafted in every detail from performance to durability using quality materials including the balanced soft-close door and rounded hob rail.
  • The large 3.5cu ft total capacity for this range gives you plenty of space to cook multiple dishes at the same time.
  • Precise cooktop controls let you sear or stir fry over instant, powerful heat. Use the high burner power or simmer a delicate sauce using the gentlest of heats.
  • With its durable surface, your cooktop simply needs a quick wipe after cooking to keep it looking good as new for years to come.
  • The door cavity cooling system keeps the heat on the inside, protecting your hands and surrounding cabinetry. The fully extendable telescopic shelving also allows easy access to any hot dishes for added safety.

Accessories

2-pc grill system (Broil pan & Grill rack) : true

Broil pan : true

Broil rack : true

Chromed shelf runners : 1 set

Full extension telescopic shelves : 2 sets (part 578776)

Hob rear trim (optional) : 3 1/8" (part 81657)

Kick strip, stainless steel (optional) : Part 81660

Small pot support : 1 (part 533981 cast)

Wok stand : 1 (part 534678)

Cleaning

Acid resistant graphite enamel : true

Dishwasher safe trivets : true

Removable oven door/s : true

Removable shelf runners : true

Controls

Interior light : true

Laser etched graphics : true

Cooktop features

Dishwasher safe trivets : true

Gas Cooktop- Sealed range top : true

Hob rail : true

Hob rear trim : 0 7/8"

LPG/Natural gas compatible : true

Cooktop performance

Dual wok burner inner / outer (LPG) x2 : 1000 - 18000BTU

Dual wok burner inner / outer (natural gas) x2 : 1000 - 18000BTU

Max burner power : 18000BTU

Number of burners : 4

Semi-rapid burner (LPG) x2 : 1500 - 8000BTU

Semi-rapid burner (natural gas) x2 : 1500 - 8000BTU

Total cooktop power : 52000BTU

Details

UPC Code : 822843813155

Gas requirements

Supply Pressure (LPG) : 11" W.C.P

Supply Pressure (natural gas) : 4" W.C.P

Installation cutout dimensions

Depth : 25 1/4"

Width : 30"

Oven features

Concealed element : true

Convection : true

Electronic ignition : true

Full extension telescopic sliding shelves : 2 sets (part 578776)

Internal light : 2 x 25W halogen (rear)

Soft open/close door : true

Storage drawer : true

Oven functions

Bake : true

Convection bake : true

Maxi Broil : true

Number of Functions : 3

Oven performance

Bake : 14000BTU

Broil : 11000BTU

CoolTouch door : Triple glazed

Shelf positions : 7

Total oven capacity : 3.5cu ft

Power requirements

AMP draw : 1A

Supply frequency : 60

Supply voltage : 120

Product Identifier

Capacity - Ranges : 3.5-3.9 cu ft

Configuration : Single

Dimension : 30"

Material / Color : Red

Type of gas : Both LPG and Natural gas

Product Type

Cooktop Technology : Gas

Oven Technology : Gas

Safety

Advanced cooling system : true

Anti-tilt bracket : true

Auto re-ignition system : true

Balanced oven door : true

CoolTouch door : true

Full extension telescopic sliding shelves : true

Non-tip shelves : true

Spill containment : 1/2 gallon

Style And Series

Product Series : Series 7

Product Style : Classic

Warranty

Warranty : 2 years

Fisher and Paykel Model # OR30SCG4R1

30" Duel Fuel Range
